MOC-175601 Ferrari F1 SF-24 1:8 Scale

Updates:
Step 319 if you noticed too much fricition in ERS then you can replace that pin axle for 3L axle with stop but you can also use parts from the default version swap pin axle from step 319 with 3L axle from step 589

Ferrari F1 SF-24 1:8 Scale

This is first car of 2024 wave Ferrari SF-24.

2024 wave brings new updates and ideas to the design. Some of the updates I added during the 2023 season but I took them further.

In 2024 main focus was put into recreating the real type of suspensions for every car. Ferrari like Haas is unique in the grid and they both only have push rod in front and pull rod in the rear section.

I also reworked rear wing its wider, the DRS flap is bigger, there are also changes to the diffuser and overall floor section.

I also reworked Air intake above driver seat section with details around HALO , the engine cover is now narrowed to the rear section.

Front wing now has 4 layers of winglets like in real car the front section also has been changed. The sloping into the front wing is shaped differently to also catch curves more accurate.

In the chassis I also recreated imitation of whole ERS system, I added battery, MGU-H, MGU-K, Turbine and also kept fuel tank on top.

Slick tires on real pictures are from new LEGO set 42171 but in the inventory are still old type of tires and rims until the new ones become widely available

Dimensions 69 x 25 x 13 cm

Weight 3,0 kg

It features:
- front push rod and rear pull rod suspension
- fake v6 engine with ERS imitation
- removable front wing but not very straightforward as now its fixed more into the front section but still possible
- removable engine cover,
- removable headrest system
- drs activate by lever in cockpit
- steering (tires winglets also turns)
- hidden details like tank, seat-belts, radiators, venturi tunnels, ERS ect
- HOG (hidden in default)
